| Multi Spectral Dynamic Imaging (MSX) | IR image with enhanced detail presentation |
| Picture-in-Picture | N/A |
| Temperature Range | –4° F to 482°F (–20° to 250°C) |
| Accuracy | ±2% or 2°C |
| Measurement Modes | Spot (center) mode
|
| Alarm | N/A |
| Emissivity Correction | Variable from 0.1 to 1.0 |
| Set-Up |
|---|
| Color Palettes | Iron, Rainbow, and Gray |
| Set-up Commands | Local adaptation of units, language, date and time formats |
| Image Storage |
|---|
| Storage Capacity | Internal memory store at least 500 sets of images |
| Storage Mode | Simultaneous storage of images in IR, visual and MSX |
| File Formats | Standard JPEG, 14-bit measurement data included |
| Other |
|---|
| Battery Type / Op Time | ~4 hours |
| Dimensions / Weight | / 1.27 lbs (0.575 kg) |
| Drop | 2 meter / 6.6 ft |
