Extech 382202 18V/3A Single Output DC Power Supply

Constant Voltage/Current digital DC power supply with dual LCD

The 382202 is a DC power supply which provides an adjustable 0 to 30 Volts and 0 to 1 Amp output. Features dual backlit LCD display for current and voltage, short circuit and overload protection. Operates from 120VAC ±10%/60Hz power source. Banana plug outputs. Complete with power cord.

18V/3A Single Output DC Power Supply Features:

• Constant voltage or current
• Dual backlit LCD displays for voltage and current
• Short circuit protection
• Current limiting
• High load/line regulation
• Low noise/ripple
• Banana plug output terminals

Specifications                                   382202
Display                                           Dual LCD
Display Accuracy (V, A)              ±(1.5%rdg); ±(2%rdg)
Voltage Output, DC                    18.0 Volts
Current Output, DC                    0 – 3.00 Amps
Ripple and Noise                        <0.5mV/<3mA
Line Regulation                          < 0.01% + 3mV/< 0.2% + 3mA
Load Regulation                        < 0.01% + 2mV/< 0.2% + 3mA
Power                                          115V/230V; 50/60Hz
Warranty                                     1 year
Dimensions (WxHxD)                9.4 x 4.25 x 6" (240 x 108 x 154mm)
Weight                                         6.6lbs. (3kg)
